Kraton My custom rear LED light is ready for the first bash!

[Barmaleus]

Hi folks!

Finally, after some design iterations, soldering and Brutal Engineering, my lovely rear LED light is ready and working (at least in a static environment).
The LED itself I got from the AliExpress, but was not impressed by the way it attaches to car (it is not protected by anything at all). Decided to design a new case for the already soldered LEDs. With the new design LED sits much deeper and is protected by the wing mount. Hopefully it lives a long life
Easily controllable from the transmitter.

Attached some pictures of the journey =)

UPD: first bash for the LED



[N.Mango]



[332_RC]

Superb! I like this design! Very cool.



[RCbuzz]

Nice work!!



[Tex Koder]

Hi folks!

Finally, after some design iterations, soldering and Brutal Engineering, my lovely rear LED light is ready and working (at least in a static environment).
The LED itself I got from the AliExpress, but was not impressed by the way it attaches to car (it is not protected by anything at all). Decided to design a new case for the already soldered LEDs. With the new design LED sits much deeper and is protected by the wing mount. Hopefully it lives a long life
Easily controllable from the transmitter.

Attached some pictures of the journey =)

View attachment 429086View attachment 429087View attachment 429088View attachment 429089View attachment 429090View attachment 429091View attachment 429092View attachment 429093View attachment 429094View attachment 429095View attachment 429097View attachment 429098View attachment 429100
View attachment 429103



[BudUMfan]

That’s badass! Very cool.



[Barmaleus]

Thanks guys! Front LED is next



[Tex Koder]

Thanks guys! Front LED is next



[parcou]

Let us know how that rear holds up. I never had much luck in the wing support since it twists and takes a lot during bashing...so much so I had to go with 3DRC flex wing mounts that have been great. I mount my rear light above the rear diff.



[Barmaleus]

Let us know how that rear holds up.

Will do!
Do you have a pic of your rear light setup? Would love to check out



[parcou]

Will do!
Do you have a pic of your rear light setup? Would love to check out

This was my first rear light attempt when I got the Kraton. Lands on the rear and wing flex killed it:

I ran across this on eBay, not sure if it is sold anymore:
LED Lights Kit For ARRMA TYPHON 6S BLX "TLR Tuned" Buggy by murat-rc
Front and rear

eBay Pic at the time

My rig:
Has lasted so far



[Barmaleus]

@parcou Ahaa, I see. Cool! You have a wheelie bar (I don't) that protects the LED box. Makes sense.
The factory rear LED box was of a similar - maybe even same - design. But I don't use the wheelie bar, so had to experiment.

(this is the original rear LED case)



[parcou]

That one looks good!!

A wheelie bar is a must for me; I don't like my rigs to look at the sky. Just a little off the ground is good enough. Hate TBone don't make these anymore....



[Barmaleus]

First bash test went positively! Love how well I can see the rear of the car now!
