Typhon Slipper Clutch Spring

matflat

Well-Known Member
Messages
53
Reaction score
52
Location
South Africa
Arrma RC's
  1. BigRock 4x4
  2. Typhon 3s
Hello Arrma Forum,

I have a strange one. On my first drive of the Typhon a few posts back, I mentioned that I has sheared the long bolt in the slipper clutch. So I ordered a new maintenance kit. I finally got around to sorting this out last week and I noticed I had a spring in it. So I put it back in the way it should be and drive it out today to give it a go and check it was ok. GOt back and tore everything down and I have no slipper clutch spring anymore. What is even weirder is that I have a spare spring but now I can't fit the slipper shaft back in at all. No idea why, do I need a spring, what the heck have I done, is there any salvation :)

Look forward to your help.

Cheers,
Mat.
